Danfoss 83096289

GEAR PUMP-LH, TRIPLE DISPL

MPN: 83096289
Category: Rugid cast iron gear pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83096289?

Danfoss GEAR PUMP-LH, TRIPLE DISPL, manufacturer part number 83096289. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Product	D-series right-hand triple
Front displacement and input drive	29.0cc / splined shaft: SAE 13 tooth spline x 1.62 inch extension
Mounting flange	SAE B 2 bolt
Porting after first section	Bearing plate, no inlet, 7/8-14 ORB outlet
Second section displacement	20.5 cc [1.25 CIR]
Porting prior to rear cover	Bearing plate, 1 1/4 inch code 61 inlet, 1 1/16-12 ORB outlet
Rear displacement	17cc [1.04 CIR]
Rear cover and porting	Cover, no inlet, 7/8-14 ORB outlet
Control setting	No controls
Relief valve pressure	No relief valve
Screws	BK: Screws
Nameplate	Standard nameplate
Special features	Standard black paint
Proposition 65	Cancer and Reproductive Harm
