Danfoss 83088204

TANDEM=GEAR PUMP GR3+GEAR PUMP GR2

MPN: 83088204
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83088204?

Danfoss TANDEM=GEAR PUMP GR3+GEAR PUMP GR2, manufacturer part number 83088204. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.3+2 family	SNW3NN + SNP2NN
B: 1st stage displacement	Displacement 22cc
C: 2nd stage displacement	Displacement 11cc
D: Rotation	Right rotation
E: Project version	With intermediate flange
F: Mounting flange	Flange SAE b with pilot D.101,6 and 2 holes for bolts
G: Drive gear	Splined SAE J498-13T-16/32-Dp Class 1FIT -for flange SAE 'B' ; rear spline DIN 5482 22 x 19 L=16,5 SC47
H: Rear cover	Standard Cover for pump
I: 1st stage inlet size	M33x2-ISO6149
J: 1st stage outlet size	M27x2-ISO6149
K: 1st stage ports position	Standard from catalogue
L: 2nd stage inlet size	M27x2-ISO6149
M: 2nd stage outlet size	M22x1,5-ISO6149
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard seal
OC DELIMITER (-)	-
P: Screws	Standard screws
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	without setting
R: Mark type	Std Sauer Danfoss Marking
S: Mark position	Position Marking standard
Slash separator	Slash
