Danfoss 83073503

PUMP-VAR-DISPL CCW H1PV100

MPN: 83073503
Category: Mobile closed-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83073503?

Danfoss PUMP-VAR-DISPL CCW H1PV100, manufacturer part number 83073503. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Series	H1 - Series
Product type	Variable pump
Frame Size	100cc/rev max/variable displacement
Rotation	Left hand - counterclockwise
Product version	Product version B
Configuration of ports	ANSI O-ring boss port configuration
Control	Manual displacement control
Orifices	P = none, A+B = none, TA+TB=1.3mm
Displacement limitation	No limiters electrical displacement control/forward neutral reverse control
Endcap type	Twin port, code 62 metric 4 bolt flange, suction filter
Mounting flange	SAE C 4 bolt flange
Input shaft	14 tooth, 12/24
Auxiliary pad	No auxiliary pad
Protection type side A	High pressure relief valve, pressure limiter plugs
High pressure setting side A	450 bar
Protection type side B	High pressure relief valve and pressure limiter plugs
High pressure setting side B	450 bar
Charge pump	20cc/rev
Filtration	Suction filtration
Charge relief pressure setting	24 bar charge pressure relief valve
Special hardware features	Manual displacement control valve plate, with handle
Paint and nametag	Black paint, Danfoss tag A
Settings	Manual displacement control standard handle orientation
