Danfoss 83054516

GEAR PUMP GR2 FIXED DISPL COVER PORTS

MPN: 83054516
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83054516?

Danfoss GEAR PUMP GR2 FIXED DISPL COVER PORTS, manufacturer part number 83054516. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 14 cc
Drive gear	Splined SAE J498-9T-16/32-Dp Class 1FIT -SC06
Inlet size	Without inlet
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	Without inlet
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for pump front BSP ports : Inlet 3/4 Gas ; Outlet 1/2 Gas
ROTATION	Product with counter-clockwise rotation
Screws	Screws standard
Seals	Product with VITON shaft seal with dust lip (type BABSL) (LEH)
Single Stage Family	Gr2 Pump-Front port
Slash separator	Slash
Valve setting	without setting
