Danfoss 83047938

PUMP-VAR DISPL, CW 90PV055

MPN: 83047938
Category: Mobile closed-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83047938?

Danfoss PUMP-VAR DISPL, CW 90PV055, manufacturer part number 83047938. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

F: DISPLACEMENT LIMITATION	No Limiters
G: END CAP PORTS	side ports
H: CHARGE PUMP	17 cc/rev
J: AUXILIARY MOUNTING PAD	SAE-A with 11 teeth coupling
K: CHARGE PRESSURE SETTING	24 bar
K: CHARGE PRS RELIEF	24 bar
L: SHAFT OPTIONS	splined shaft , 14 teeth, pitch = 12 / 24
M: CONTROL	ms-connector, standard porting, dual coil ( 14 - 85 mA)
N: FILTRATION	pressure integral (long filter)
P: HIGH PRESSURE REGULATION	Port A & B: fast response PL, up to 450 bar settings
Proposition 65	Cancer and Reproductive Harm
Series 90 Displacement	55 Cubic Centimeters per Revolution
Series 90 Product Line	Series 90
Series 90 Rotation	Clockwise (Right hand) Rotation
T: CONTROL ORIFICES	MDC (P) 0,81 (TA) none* (TB) none* (A) none (B) none
W: SPECIAL HARDWARE FEATURES	CP15 +0.5 VALVE PLATE
Y: HIGH PRESSURE SETTING A	Port A = 420 Bar / 6090 PSI
Y: HIGH PRS SETTING PORT A	Port A = 420 Bar / 6090 PSI
Z: HIGH PRESSURE SETTING B	Port B = 420 Bar / 6090 PSI
Z: HIGH PRS SETTING PORT B	Port B = 420 Bar / 6090 PSI

83047938: frequently asked questions

When can 83047938 be shipped?

83047938 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 83047938 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 83047938 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 83047938, subject to availability and destination.
