Danfoss 83044192

PUMP-VAR DISPL MPV046C

MPN: 83044192
Category: Mobile closed-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83044192?

Danfoss PUMP-VAR DISPL MPV046C, manufacturer part number 83044192. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

S40_PRODUCT_RES	Variable pump
BASE DISPLACEMENT	46cc/rev (2.80cir)
TYPE	25cc product type
C: SWASHPLATE	Pressure balanced swashplate
D: SEAL GROUP	Shaft seal with electrical displacement control/hydraulic displacement control
E: INPUT SHAFT/AUXILIARY DRIVE	15 tooth 16/32 spline / 13 tooth 16/32 spline, B auxiliary
F: ROTATION & VALVE PLATE	Clockwise, valve plate
G: CHARGE PUMP DISPLACEMENT	13.99 cc/rev (0.85CIR) charge pump displacement
H: CHARGE PRS RLF VALVE SET	21.5 bar (310 psi)
J: FILTRATION	Remote pressure filtration without bypass
K: DISPLACEMENT LIMITERS	Full displacement
L: BYPASS VALVE	Bypass valve - no orifice
M: SYSTEM PRESSURE PROTECTION	250 bar (3625 psi) / 250 bar (3625 psi)
N: CONTROL	Electrical displacement control, dual coil, oil filled, Packard connector 4-pin, 23-132 mA
P: HANDLE POSITION	Not applicable
R: CONTROL ORIFICE DIAMETER	Electrical displacement control/hydraulic displacement control/forward neutral reverse - supply=0.037, drain=0.037
S: AUXILIARY MOUNTING PAD	Aux flange SAE B, lift bracket side 2
T: SPECIAL HARDWARE FEATURES	None, black paint, Danfoss tag
ZZ: SPCL FEATURES (NON-HRDW)	None
Product	Variable pump
Proposition 65	Cancer and Reproductive Harm
Size/Dimensions	0.001
