Danfoss 83028043

GEAR PUMP GR2 FIXED DISPL

MPN: 83028043
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83028043?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 83028043. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 19 cc
Drive gear	Splined SAE J498-11T-16/32-Dp Class 1FIT -SC06 SKP2
Inlet size	20x40xM6
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	WIRTGEN Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts with seal on pilotdiameter (BAW)
O-Ring, Inside Diameter	Slash
Outlet size	15x35xM6
Ports position	Port type Bx-Bx for flange SAE-A as per catalogue (inverted std. position from flange to cover) LCX
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Standard cover for pump
ROTATION	Product with clockwise rotation
Screws	Product with galvanized assembly screws ( +nuts, washers or cap nuts if listed on the Bill of Material )
Seals	Standard seal
Single Stage Family	Gr2 Hi.Torque Pump
Slash separator	Slash
Valve setting	without setting
