Danfoss 83018853

GEAR PUMP GR2 FIXED DISPL

MPN: 83018853
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83018853?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 83018853. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 14 cc
Drive gear	Splined SAE J498-9T-16/32-Dp Class 1FIT - rear spline DIN 5482 17 x 14 L=14 (type 36 vers.2)
Inlet size	3/4 GAS
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	1/2 GAS
Ports position	Standard from catalogue
Project version	Standard with interface SAE
Proposition 65	Cancer and Reproductive Harm
Rear cover	Not assigned (with intermediate flange instead cover)
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Main stage
Slash separator	Slash
Valve setting	without setting
