Danfoss 83015800

PUMP-VAR-DISPL 42PV051 CW

MPN: 83015800
Category: Mobile closed-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 83015800?

Danfoss PUMP-VAR-DISPL 42PV051 CW, manufacturer part number 83015800. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Series 42 Product	Series 42 Single Pump
Y: DISPLACEMENT	51cc/REV (3.11 CU. IN.) WITHOUT SPEED SENSING
C: INPUT SHAFT CONFIGURATION	13 TEETH 16/32 PITCH
D: CONTROL TYPE	MDC, Linear, Std-Deadband, Low Force Torsion Spring, Switch-None, Neutral Override-None, Std-Handle, Low Gain Spool
E: CONTROL RESPONSE TIME	SLOW (0.8, 4.0, 4.0, 0.8) (PREFERRED)
F: PORT STYLE/HOUSING	Full Feature: SAE Threaded O-ring Boss, Loop Flushing, Filter pad options, Speed Sensor Possible
Q: LOOP FLUSHING/COOLING	Loop Flushing/ Cooling, Orifice Option 3, Use with Charge Pressure Settings of 18dBar and higher.
R: FILTRATION	Remote Pressure Filtration (Full Flow), with Adapter
G: CHARGE/IMPLEMENT PUMP	Internal Charge and Auxiliary Flow Pump, 15.6 cc/rev
S: CHARGE RELIEF SETTING	20 BAR (290 PSI)
T: SPECIAL DRIVE FEATURES	NONE
U: REAR AUXILARY MOUNTING PAD	NONE
H: SYS PRS PROTECTION - PORT A	230BAR (3330PSI) HPRV
J: SYS PRS PROTECTION - PORT B	230BAR (3330PSI) HPRV
K: LOOP BYPASS VALVE	BYPASS VALVE
L: DISPL LIMITERS - SIDE 1	NONE
M: DISPL LIMITERS - SIDE 2	NONE
N: SPECIAL HDWR	NONE
P: SPECIAL FEATURES (NON-HDWR)	BLACK PAINT, STANDARD TAG, DANFOSS LOGO
Proposition 65	Cancer and Reproductive Harm
ROTATION	Right-hand, CW
