Home / Danfoss (Drives) / Mobile closed-circuit piston pumps / Danfoss 83013169

Danfoss 83013169

PUMP-VAR-DISPL CCW 90PV130

MPN: 83013169
Category: Mobile closed-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 83013169?

Danfoss PUMP-VAR-DISPL CCW 90PV130, manufacturer part number 83013169. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

F: DISPLACEMENT LIMITATION	No Limiters
G: ENDCAP PORTS	twin ports
H: CHARGING SYSTEM	34 cc/rev
J: AUXILARY MOUNTING PAD	SAE-C with 14 T coupling, 4 bolt adapter,(2) ½-13 UNC tapped holes for support of pump
K: CHARGE PRESSURE SETTING	24 bar
L: INPUT SHAFT	13T 8/16 Pitch
M: CONTROL	weather-pack connector,standard. porting, dual coil (14 - 85 mA)
M: CONTROLS	weather-pack connector,standard. porting, dual coil (14 - 85 mA)
N: FILTRATION	pressure integral (short filter)
P: HIGH PRESSURE REGULATION	Port A & B: fast response PL, up to 450 bar settings
Proposition 65	Cancer and Reproductive Harm
SERIES 90 PUMP TYPE	Series 90 130cc/rev counter-clockwise rotation
T: CONTROL ORIFICES	EDC 1 & 3, EFPC (P) 0,81 (TA) 1,3* (TB) 1,3* (A) none (B) none
W: SPECIAL HARDWARE FEATURES	CP15 +0.5 VALVE PLATE
Y: HIGH PRESSURE SETTING A	350 Bar
Z: HIGH PRESSURE SETTING B	350 Bar

83013169: frequently asked questions

When can 83013169 be shipped?

83013169 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 83013169 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 83013169 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 83013169, subject to availability and destination.
