BACK TO BACK (DUAL MANU. VARIABLE DISP), ADDRA3JRTT41B03JRTT100LECAK0PDB

Name: Danfoss 78364-RDW-02 – BACK TO BACK (DUAL MANU. VARIABLE DISP), ADDRA3JRTT41B03JRTT100LECAK0PDB
Brand: Danfoss (Drives)
SKU: 78364-RDW-02

MPN: 78364-RDW-02 · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mobile closed-circuit piston pumps
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 78364-RDW-02 be shipped?

78364-RDW-02 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 78364-RDW-02 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 78364-RDW-02 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 78364-RDW-02, subject to availability and destination.

Danfoss BACK TO BACK (DUAL MANU. VARIABLE DISP), ADDRA3JRTT41B03JRTT100LECAK0PDB, manufacturer part number 78364-RDW-02. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Additional functions	None
Aux port and bypass valve	2x .750-16 UNF-2B SAE o-ring port, top, plugged (C1); bottom (C2); no bypass valve
Auxiliary mount features	Integral mount series "26" (RH rotation suction port bottom\LH rotation suction port top) with 35 tooth input
Auxiliary pump number	26506-R01 multiple gear pump series "26" 1.02/1.02/1.02
Brand	Danfoss
CODE TITLE	Dual manually variable displacement axial piston pump with SAE J744 flange 101-2 (2 bolt b)
Control shaft front	Left; 19.1 [.75] square shaft without bolt groove; 128 [5.04] from centerline to control shaft end
Control shaft rear	Left; 19.1 [.75] square shaft without bolt groove; 128 [5.04] from centerline to control shaft end
CPRV setting and routing	None
Design code	B
Displacement and RG kit front	49.2 cm3/r [3.00 in3/r]; rotating kit- standard
Displacement and RG kit rear	49.2 cm3/r [3.00 in3/r]; rotating kit- standard
Drain size and location front	2x .750-16 UNF-2B SAE o-ring port, top (D1); bottom (D2)
Drain size and location rear	2x .750-16 UNF-2B SAE o-ring port, top (D3); bottom, plugged (D4)
Flow rate gpm	46.8
Flow rate lpm	177.0
Identification	Macdon
Input shaft	15 tooth external spline, 16/32 pitch, 24.981 [.9835] major diameter; 46 [1.81] shaft extension
Input shaft rotation	Right hand rotation (CW)
Main ports A and B	4x 1.0625-12 UN-2B SAE o-ring ports; front ports top, rear ports bottom
Maximum output speed	3600
Maximum temperature C	107.00
Maximum temperature F	225.00
Model Code 1	ADDRA3JRTT41B03JRTT100LECAK0PD
Model Code 2	B
Mounting flange	2-bolt-B
Note	For more info, contact Danfoss
Output torque lbf-in2	2387.3
Output torque Nm	269.7
Paint	Gray per spec 209-13P
Relief set front main port A	344.7 bar [5000 lbf/in2]
Relief set front main port B	344.7 bar [5000 lbf/in2]
Relief set rear main port A	344.7 bar [5000 lbf/in2]
Relief set rear main port B	344.7 bar [5000 lbf/in2]
Special features	Mounting holes, 4x .375-16 UNC-2B thd, 15.2 [.60] min full thd, 50.8 [2.000] between mounting holes; increased torque rating foraux pump; fluorocarbon drive shaft seal
Valve plate front	Type 10
Valve plate rear	Type 10
Working pressure bar	345
Working pressure psi	5000
