Danfoss 721AR00034A

Industrial vane pump

MPN: 721AR00034A
Category: Industrial vane pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 721AR00034A?

Danfoss V2010 1F9S3S 1BA12L 167, V2010 1F9S3S 1BA12L 167, manufacturer part number 721AR00034A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

PUMP TYPE	VANE PUMP
Series	DOUBLE SQUARE PUMP
Mounting type	2 BOLT FLANGE SAE-B SIZE
INLET PORT TYPE	4 BOLT FLANGE
RING CAPACITY COVER SIDE	3 GPM
RING CAPACITY SHAFT END	9 GPM
OUTLET PORT TYPE SHAFT END	1.0625-12 UN-2B THREAD
Shaft type	3/16 SQUARE KEY,MAJOR DIA-.875, EXTENSION-2.31
OUTLETCOVER PORT ORIENTATION	OUTLET#2: 135 ° CCW FROM INLET PORT , OUTLET#1:90 °CCW FROM INLET PORT
OUTLET PORT TYPE COVER SIDE	.750-16 UN-2B THREAD
DESIGN CODE	12-DESIGN CODE
Shaft rotation	LH CCW ROTATION VIEWED FROM SHAFT END
SPECIAL FEATURE SUFFIX	RING & ROTOR CLEARANCES TO MATCH .0015 TO .0017 AT COVER END
Brand	Vickers by Danfoss
IPM FRAME SIZE	V2010 Double Pump
Model Code 1	V2010 1F9S3S 1BA12L 167
