Danfoss 718AR00299A

35VQHTAS35A2203CA30R, 35VQHTAS35A2203CA30R

MPN: 718AR00299A
Category: Industrial vane pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 718AR00299A?

Danfoss 35VQHTAS35A2203CA30R, 35VQHTAS35A2203CA30R, manufacturer part number 718AR00299A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

PRESSURE	HIGH PRESSURE
PUMP TYPE	VANE TYPE PUMP VQ-MOBIL
Series	INTRAVANE PUMP SERIES WITH STANDARD BEARING
Shaft type	203 - SAE, STRAIGHT SQ. KEY
ADPMTG ORT ADP END	A ADAPTER- ROTATED 45⁰ CW WITH RESPECT TO PUMP MTG. FLG. B OR C ADAPTER- IN LINE WITH PUMP MTG. FLANGE
BODY MOUNTING FLG	SAE J744 MOUNTING FLANGE
CPLG FOR TAND PUMP	SAE SPLINED COUPLING INCLUDED WITH PUMP
DESIGN NO MOD	DESIGN CODE-30
ROT FROM SHAFT END	RIGHT HAND OR CLOCKWISE
ROTATING GROUP CAP	35 GPM
SAE PORT CXN	INLET-4 BOLT FLG. OUTLET-4 BOLT FLG.
THRU CXN MTG ADP	TWO BOLT SAE 'A' FLANGE
THRU DRIVE	THRU DRIVE
O POS FROM ADP END	IN LINE WITH INLET PORT
Brand	Vickers by Danfoss
IPM FRAME SIZE	35VQH Single Pump
Model Code 1	35VQHTAS35A2203CA30R
