Danfoss 717-0098-032

VMQ3453525160135090A01AD DGANR00A032, VMQ3453525160135090A01AD DGANR00A032

MPN: 717-0098-032
Category: Industrial vane pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 717-0098-032?

Danfoss VMQ3453525160135090A01AD DGANR00A032, VMQ3453525160135090A01AD DGANR00A032, manufacturer part number 717-0098-032. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

PRODUCT	VMQ VANE PUMP TRIPLE SERIES
FRAME SIZE FRONT SECTION	140-268 cm3/r [8.54-16.35 in3/r]
FRAME SIZE MIDDLE SECTION	90-140 cm3/r [5.49-8.54 in3/r]
FRAME SIZE REAR SECTION	10-80 cm3/r [.62-4.88 in3/r]
DISPLACEMENT FRONT SECTION	160.0 cm3/r [9.76 in3/r] 45 FRAME SIZE
DISPLACEMENT MIDDLE SECTION	135.0 cm3/r [8.24 in3/r] 35 FRAME SIZE
DISPLACEMENT REAR SECTION	90.0 cm3/r [5.49 in3/r] 25 FRAME SIZE
FRONT MOUNTING FLANGE TYPE	SAE J744 127-2 (SAE C) 2 BOLT: 127.00 [5.000] DIA. X 12.4 [.49] PILOT, 17.6 [.69]DIA. SLOTS ON 181.0 [7.13] DIA BOLT CIRCLE
INPUT SHAFT TYPE	KEYED SHAFT PER SAE J744 (31.75 [1.250]DIA. FOR 35 FRAME, 38.10 [1.500] DIA. FOR45 FRAME)
Port Type	4-BOLT FLANGE PER SAE J518 WITH ENGLISHTHREADS-INLET, 4-BOLT FLANGE PER SAE J518WITH ENGLISH THREADS-FRONT OUTLET,4-BOLTFLANGE PER SAE J518 WITH ENGLISH THREADS MIDDLE OUTLET, 4-BOLT FLANGE PER SAE J518 WITH ENGLISH THREADS-REAR OUTLET
FRONT OUTLET PORT POS COVEREND	FRONT OUTLET PORT 90 DEG. CLOCKWISE FROMFRONT INLET PORT
MIDLE OUTLET PORT POS COVEREND	MIDDLE OUTLET PORT 90 DEG. CLOCKWISE FROMINLET PORT
REAR OUTLET PORT POS COVER END	REAR OUTLET PORT IN-LINE WITH INLET PORT(NOT AVAILABLE WITH 35,25,25)
SHAFT SEAL	SINGLE, PRIMARY
Seal type	BUNA N
PUMP ROTATION SHAFT END VIEW	RIGHT HAND (CLOCKWISE)
SPECIAL FEATURES	NONE
Paint	PAINTED BLUE
Customer identification	NONE
DESIGN CODE	THIRTY-SECOND
Brand	Vickers by Danfoss
IPM FRAME SIZE	453525VMQ Tripple Pump
Model Code 1	VMQ3453525160135090A01AD DGANR
Model Code 2	00A032
