Danfoss 717-0086-032

VMQ3453525195158080A09ACCGANR00A032, VMQ3453525195158080A09ACCGANR00A032

MPN: 717-0086-032
Category: Industrial vane pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 717-0086-032?

Danfoss VMQ3453525195158080A09ACCGANR00A032, VMQ3453525195158080A09ACCGANR00A032, manufacturer part number 717-0086-032. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

PRODUCT	VMQ VANE PUMP TRIPLE SERIES
FRAME SIZE FRONT SECTION	140-268 cm3/r [8.54-16.35 in3/r]
FRAME SIZE MIDDLE SECTION	90-140 cm3/r [5.49-8.54 in3/r]
FRAME SIZE REAR SECTION	10-80 cm3/r [.62-4.88 in3/r]
DISPLACEMENT FRONT SECTION	195.0 cm3/r [11.89 in3/r] 45 FRAME SIZE
DISPLACEMENT MIDDLE SECTION	158.0 cm3/r [9.64 in3/r] 35 FRAME SIZE
DISPLACEMENT REAR SECTION	80.0 cm3/r [4.88 in3/r] 25 FRAME SIZE
FRONT MOUNTING FLANGE TYPE	SAE J744 127-2 (SAE C) 2 BOLT: 127.00 [5.000] DIA. X 12.4 [.49] PILOT, 17.6 [.69]DIA. SLOTS ON 181.0 [7.13] DIA BOLT CIRCLE
INPUT SHAFT TYPE	SPLINED SHAFT PER SAE J744 (C FOR 45 FRAME)
Port Type	4-BOLT FLANGE PER SAE J518 WITH ENGLISHTHREADS-INLET, 4-BOLT FLANGE PER SAE J518WITH ENGLISH THREADS-FRONT OUTLET,4-BOLTFLANGE PER SAE J518 WITH ENGLISH THREADS MIDDLE OUTLET, 4-BOLT FLANGE PER SAE J518 WITH ENGLISH THREADS-REAR OUTLET
FRONT OUTLET PORT POS COVEREND	FRONT OUTLET PORT IN-LINE WITH INLET PORT
MIDLE OUTLET PORT POS COVEREND	MIDDLE OUTLET PORT IN-LINE WITH INLET PORT
REAR OUTLET PORT POS COVER END	REAR OUTLET PORT IN-LINE WITH INLET PORT(NOT AVAILABLE WITH 35,25,25)
SHAFT SEAL	SINGLE, PRIMARY
Seal type	BUNA N
PUMP ROTATION SHAFT END VIEW	RIGHT HAND (CLOCKWISE)
SPECIAL FEATURES	NONE
Paint	PAINTED BLUE
Customer identification	NONE
DESIGN CODE	THIRTY-SECOND
Brand	Vickers by Danfoss
IPM FRAME SIZE	453525VMQ Tripple Pump
Model Code 1	VMQ3453525195158080A09ACCGANR0
Model Code 2	0A032
