Danfoss 716-0094-032

VMQ3352525112050050A01AA AAANR00A032, VMQ3352525112050050A01AA AAANR00A032

MPN: 716-0094-032
Category: Industrial vane pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 716-0094-032?

Danfoss VMQ3352525112050050A01AA AAANR00A032, VMQ3352525112050050A01AA AAANR00A032, manufacturer part number 716-0094-032. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

PRODUCT	VMQ VANE PUMP TRIPLE SERIES
FRAME SIZE FRONT SECTION	90-140 cm3/r [5.49-8.54 in3/r]
FRAME SIZE MIDDLE SECTION	10-80 cm3/r [.62-4.88 in3/r]
FRAME SIZE REAR SECTION	10-80 cm3/r [.62-4.88 in3/r]
DISPLACEMENT FRONT SECTION	112.0 cm3/r [6.83 in3/r] 35 FRAME SIZE
DISPLACEMENT MIDDLE SECTION	50.0 cm3/r [3.05 in3/r] 25 FRAME SIZE
DISPLACEMENT REAR SECTION	50.0 cm3/r [3.05 in3/r] 25 FRAME SIZE
FRONT MOUNTING FLANGE TYPE	SAE J744 127-2 (SAE C) 2 BOLT: 127.00 [5.000] DIA. X 12.4 [.49] PILOT, 17.6 [.69]DIA. SLOTS ON 181.0 [7.13] DIA BOLT CIRCLE
INPUT SHAFT TYPE	KEYED SHAFT PER SAE J744 (31.75 [1.250]DIA. FOR 35 FRAME, 38.10 [1.500] DIA. FOR45 FRAME)
Port Type	4-BOLT FLANGE PER SAE J518 WITH ENGLISHTHREADS-INLET, 4-BOLT FLANGE PER SAE J518WITH ENGLISH THREADS-FRONT OUTLET,4-BOLTFLANGE PER SAE J518 WITH ENGLISH THREADS MIDDLE OUTLET, 4-BOLT FLANGE PER SAE J518 WITH ENGLISH THREADS-REAR OUTLET
FRONT OUTLET PORT POS COVEREND	FRONT OUTLET PORT OPPOSITE INLET PORT
MIDLE OUTLET PORT POS COVEREND	MIDDLE OUTLET PORT OPPOSITE INLET PORT
REAR OUTLET PORT POS COVER END	REAR OUTLET PORT 135 DEG. COUNTERCLOCKWISE FROM INLET PORT (NOT AVAILABLE WITH45,35,25)
SHAFT SEAL	SINGLE, PRIMARY
Seal type	BUNA N
PUMP ROTATION SHAFT END VIEW	RIGHT HAND (CLOCKWISE)
SPECIAL FEATURES	NONE
Paint	PAINTED BLUE
Customer identification	NONE
DESIGN CODE	THIRTY-SECOND
Brand	Vickers by Danfoss
IPM FRAME SIZE	352525VMQ Tripple Pump
Model Code 1	VMQ3352525112050050A01AA AAANR
Model Code 2	00A032
