Danfoss 710-0101-032

VMQ145T240BJ0132AABANR 00A032, VMQ145T240BJ0132AABANR 00A032

MPN: 710-0101-032
Category: Industrial vane pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 710-0101-032?

Danfoss VMQ145T240BJ0132AABANR 00A032, VMQ145T240BJ0132AABANR 00A032, manufacturer part number 710-0101-032. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

PRODUCT	VMQ SINGLE SERIES VANE PUMP
Frame Size	140-268 cm3/r [8.54-16.35 in3/r]
DISPLACEMENT	240.0 CM3/R [14.65 IN3/R] 45 FRAME SIZE
FRONT MOUNTING FLANGE TYPE	SAE J744 127-2 (SAE C) 2 BOLT: 127.00[5.000] DIA. X 12.4 [.49] PILOT, 17.6 [.69]DIA. SLOTS ON 181.0 [7.13] DIA. BOLT CIRCLE
INPUT SHAFT TYPE	KEYED SHAFT PER SAE J744 (25.40 [1.000]DIA. FOR 25 FRAME, 31.75 [1.250] DIA. FOR35 FRAME, 38.10 [1.500] DIA. FOR 45 FRAME)
INLET PORT TYPE	4-BOLT FLANGE PER SAE J518 WITH ENGLISHTHREADS
OUTLET PORT TYPE	4-BOLT FLANGE PER SAE J518 WITH ENGLISHTHREADS
OUTLET PORT POS COVER END VIEW	OUTLET PORT 90 DEG. COUNTER-CLOCKWISE FROMINLET PORT
SHAFT SEAL	SINGLE, PRIMARY
Seal type	BUNA N
PUMP ROTATION SHAFT END VIEW	RIGHT HAND (CLOCKWISE)
SPECIAL FEATURES	NONE
Paint	PAINTED BLUE
Customer identification	NONE
DESIGN CODE	THIRTY-SECOND
ADAPT MOUNT ORIENT COVER END	(SAE C) ADAPTER FLANGE IN-LINE WITHMOUNTING FLANGE, 35 & 45 FRAME SIZE
OUTPUT SHAFT COUPLING	C SPLINE SHAFT PER SAE J744 32-4, 35 & 45FRAME SIZE ONLY
PUMP TYPE	THRU DRIVE
Brand	Vickers by Danfoss
IPM FRAME SIZE	45VMQ Single Pump
Model Code 1	VMQ145T240BJ0132AABANR 00A032
