Danfoss 66GA
COUPLING,6000,M,3/4,CS,-12MNPTF,NBR
- MPN
- 66GA
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 66GA?
Danfoss COUPLING,6000,M,3/4,CS,-12MNPTF,NBR, manufacturer part number 66GA. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| EAN/UPC | 678146167149 |
| Angle shape | Straight |
| Body size | 3/4 |
| Burst pressure min bar | 61 |
| Burst pressure min psi | 880 |
| Compliances | A-A-59439 |
| Connection style | Manual connect |
| End size 2 | -12 |
| End type 1 | Male pipe (NPTF) |
| Finish plating | Zinc |
| Flow rate GPM | 935.17 |
| Flow rate LPM | 3540.00 |
| Fluid compatibility | Air, Gases and liquids |
| Hex size 1 IN | 1.060 |
| Hex size 1 MM | 26.924 |
| Item type | Male half |
| Latch type | Push/pull |
| Product material | Carbon steel |
| Seal material | Nitrile (NBR) |
| Valve type | 2 way |
| Working pressure max psi | 220 |
| Working pressure max BAR | 15 |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
66GA: frequently asked questions
When can 66GA be shipped?
66GA is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 66GA in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 66GA and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 66GA, subject to availability and destination.
