Danfoss 634833

RCG 10 D1 30, RCG10D130

MPN: 634833
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 634833?

Danfoss RCG 10 D1 30, RCG10D130, manufacturer part number 634833. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation Type	Pilot operated
Adjustment range	17.2-70 bar (250-1000 psi)
Adjustment type	Screw with locknut
Brand	Vickers by Danfoss
Check valve	Yes
Design Series	30 Series
Drain	Internal
Electrical connection	None
Flow rate lpm	284.0
Flow rate USGPM	75.0
Fluid Cleanliness	19/17/14 Micron
Fluid compatibility	Petroleum oils
Hi-vent spring	No
Indicator Light	No
Maximum pressure BAR	210
Maximum pressure PSI	3000
Model Code 1	RCG10D130
Performance	Standard
Product height in	11.110
Product height mm	282.194
Product length in	4.700
Product length mm	119.380
Product width in	5.120
Product width mm	130.048
Seal material	Nitrile
Size	Size 10
Special feature	None
Stage	Two stage
Valve Mount Type	Subplate/manifold mounted
Valve type	Pressure control valve
Working temperature max C	70
Working temperature max F	158
Working temperature min C	-20
Working temperature min F	-4
