Danfoss 634094

MPN: 634094
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 634094?

Danfoss RG 10 DP2 30, RG10DP230, manufacturer part number 634094. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation Type	Pilot operated
Adjustment range	17.2-70 bar (250-1000 psi)
Adjustment type	Screw with locknut
Brand	Vickers by Danfoss
Check valve	No
Design Series	30 Series
Drain	External
Electrical connection	None
Flow rate lpm	284.0
Flow rate USGPM	75.0
Fluid Cleanliness	19/17/14 Micron
Fluid compatibility	Petroleum oils
Hi-vent spring	No
Indicator Light	No
Maximum pressure BAR	210
Maximum pressure PSI	3000
Model Code 1	RG10DP230
Performance	Standard
Product height in	11.110
Product height mm	282.194
Product length in	4.700
Product length mm	119.380
Product width in	4.190
Product width mm	106.426
Seal material	Nitrile
Size	Size 10
Special feature	None
Stage	Two stage
Valve Mount Type	Subplate/manifold mounted
Valve type	Pressure control valve
Working temperature max C	70
Working temperature max F	158
Working temperature min C	-20
Working temperature min F	-4

634094: frequently asked questions

When can 634094 be shipped?

634094 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 634094 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 634094 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 634094, subject to availability and destination.
