Danfoss 600AD00089C

GD5S20AD06ABAA17RAB0C

MPN: 600AD00089C
Category: Lumi aluminum gear pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 600AD00089C?

Danfoss GD5S20AD06ABAA17RAB0C, manufacturer part number 600AD00089C. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Brand	Danfoss
Design code	Third
Displacement	20.0 cm3/r [1.22 in3/r]
Identification	None
Inlet port	1.0625-12 un-2b SAE o-ring ports (SAE #12)
Input shaft	9 teeth, 16/32 dp 30 deg involute spline, 20.0 [0.79] min full spline,15.56 [0.61] dia, flat root side fit, shaft ext 31.5 [1.24], reinforcedfillet
Mounitng	SAE a 2 bolt, 82.50 [3.25] pilot dia. 11.0 [0.43] dia holes slotted on 106.4 [4.19] dia. circle
Outlet port	.875-14 unf-2b SAE o-ring ports (SAE #10)
Paint	Epoxy coated black primer (aluminium surfaces have adhesion limitations)
Product	External gear pump
Rotation	Right handed cw
Size	Frame size
Special features	None
Unit type	Single
