Danfoss 593907

RCG 03 Z4 30, RCG03Z430

MPN: 593907
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 593907?

Danfoss RCG 03 Z4 30, RCG03Z430, manufacturer part number 593907. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation Type	Pilot operated
Adjustment range	4.1-8.5 bar (60-125 psi)
Adjustment type	Screw with locknut
Brand	Vickers by Danfoss
Check valve	Yes
Design Series	30 Series
Drain	Internal
Electrical connection	None
Flow rate lpm	45.0
Flow rate USGPM	12.0
Fluid Cleanliness	19/17/14 Micron
Fluid compatibility	Petroleum oils
Hi-vent spring	No
Indicator Light	No
Maximum pressure BAR	140
Maximum pressure PSI	2000
Model Code 1	RCG03Z430
Performance	Standard
Product height in	7.030
Product height mm	178.562
Product length in	2.810
Product length mm	71.374
Product width in	3.560
Product width mm	90.424
Seal material	Nitrile
Size	Size 03
Special feature	None
Stage	Two stage
Valve Mount Type	Subplate/manifold mounted
Valve type	Pressure control valve
Working temperature max C	70
Working temperature max F	158
Working temperature min C	-20
Working temperature min F	-4
