Danfoss 57

COUPLING,500,M,1/2,B,-12NPT

MPN: 57
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 57?

Danfoss COUPLING,500,M,1/2,B,-12NPT, manufacturer part number 57. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146138699
Angle shape	Straight
Body size	1/2
Burst pressure min bar	138
Burst pressure min psi	2000
Connection style	Manual connect
End size 2	-12
End type 1	Male push to connect
End type 2	Female pipe (NPTF)
Finish plating	Zinc
Flow rate GPM	538.00
Flow rate LPM	2036.55
Fluid compatibility	Compressed air, Gases and liquids
Hex size 1 IN	1.190
Hex size 1 MM	30.226
Item type	Male half
Latch type	Push/pull
Product height in	1.370
Product height mm	34.798
Product length in	2.440
Product length mm	61.976
Product material	Carbon steel
Product width in	1.370
Product width mm	34.798 mm
Seal material	Nitrile (NBR)
Valve type	2 way
Working pressure max psi	500
Working pressure max BAR	34
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
