COUPLING,FF,F,2",CS,-40UNF,NBR
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Danfoss Hansen® quick disconnect couplings |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 50FFS250UN be shipped?
50FFS250UN is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 50FFS250UN in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 50FFS250UN and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 50FFS250UN, subject to availability and destination.
Danfoss COUPLING,FF,F,2",CS,-40UNF,NBR, manufacturer part number 50FFS250UN. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| EAN/UPC | 678146156556 |
| Air inclusion max cc | 0.26 |
| Air inclusion max in3 | 0.02 |
| Angle shape | Straight |
| Body size | 2" |
| Burst pressure min bar | 675 |
| Burst pressure min psi | 9790 |
| Certifications | ISO 16028 |
| Compliances | PED 2014/68 EU Article 4.3, REACH, RoHS Compliant |
| Connection style | Manual connect |
| End size 1 | -32 |
| End type 1 | Female ORB port ISO 11926-1 |
| Finish plating | Guardian Seal |
| Flow rate GPM | 184.90 |
| Flow rate LPM | 699.92 |
| Fluid loss cc | 0.39000 |
| Fluid loss in3 | 0.02400 |
| Hex size 1 IN | 3.150 |
| Hex size 1 MM | 80.010 |
| Item type | Female half |
| Product material | Carbon steel |
| Safety locking mechanism | Sleeve lock |
| Seal material | Nitrile (NBR) |
| Thread size 1 | 2 1/2-12 UN |
| Torque lbs-ft | 84.30 |
| Valve type | 2 way |
| Working pressure max psi | 3260 |
| Working pressure max BAR | 225 |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -25 |
| Working temperature min F | -13 |
