Danfoss 50400

COUPLING,5000,F,1/2,B,-4BARB,NBR

MPN: 50400
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 50400?

Danfoss COUPLING,5000,F,1/2,B,-4BARB,NBR, manufacturer part number 50400. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146103062
Angle shape	Straight
Body size	1/2
Burst pressure min bar	138
Burst pressure min psi	2000
Connection style	Manual connect
End type 1	Female Push to Connect
End type 2	Line/hose/tube
Flow rate GPM	539.00
Flow rate LPM	2040.34
Fluid compatibility	Air, Gases and liquids
Item type	Female half
Latch type	Push/pull
Product height in	0.250
Product height mm	6.350
Product length in	3.290
Product length mm	83.566
Product material	Brass
Product width in	0.250
Product width mm	6.350 mm
Safety locking mechanism	Pin lock
Seal material	Nitrile (NBR)
Valve type	2 way
Working pressure max psi	500
Working pressure max BAR	34
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
