Danfoss 4T8DLA6

HOSE FTG, 4T/06, DKOL/08, CS, 45D

MPN: 4T8DLA6
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T8DLA6?

Danfoss HOSE FTG, 4T/06, DKOL/08, CS, 45D, manufacturer part number 4T8DLA6. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.630
A dimension MM	66.800
Angle shape	45 Degree
Compatible hose ID IN	0.380
Compatible hose ID MM	9.525
Construction Style	Crimp
Drop dimension IN	0.750
Drop dimension MM	19.00
End size 1	-8
End type 1	24 deg. DKO swivel light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.748
Hex size 1 MM	19.000
Hose cut off factor IN	1.640
Hose cut off factor MM	41.500
Hose size	-6
Inside diameter IN	0.260
Inside diameter MM	6.700
Product height in	1.181
Product height mm	30.000
Product length in	2.755
Product length mm	70.000
Product material	Carbon steel
Product width in	0.984
Product width mm	25.000 mm
Seal material	Nitrile (NBR)
Thread sealant	No
Thread size 1	M16x1.5
Working pressure max BAR	275
Working pressure max PSI	4000
