Danfoss 4T6DLB4

HOSE FTG, 4T/04, DKOL/06, CS, STR

MPN: 4T6DLB4
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T6DLB4?

Danfoss HOSE FTG, 4T/04, DKOL/06, CS, STR, manufacturer part number 4T6DLB4. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.020
A dimension MM	51.200
Angle shape	Straight
Compatible hose ID IN	0.250
Compatible hose ID MM	6.350
Construction Style	Crimp
End size 1	-6
End type 1	24 deg. DKO swivel light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.669
Hex size 1 MM	17.000
Hose cut off factor IN	1.090
Hose cut off factor MM	27.700
Hose size	-4
Inside diameter IN	0.170
Inside diameter MM	4.200
Product height in	1.771
Product height mm	45.000
Product length in	2.322
Product length mm	59.000
Product material	Carbon steel
Product width in	0.984
Product width mm	25.000 mm
Thread sealant	No
Thread size 1	M14X1.5
Working pressure max BAR	330
Working pressure max PSI	4800
