Danfoss 4T10DL6

HOSE FTG, 4T/06, DKOL/10, CS, STR

MPN: 4T10DL6
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T10DL6?

Danfoss HOSE FTG, 4T/06, DKOL/10, CS, STR, manufacturer part number 4T10DL6. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.090
A dimension MM	53.100
Angle shape	Straight
Application	Chemical, Fluid transfer, Food and beverage, Injection moulding, Marine, Medical, Pressure washing, Steam cleaning
Brand	Synflex Optimum by Danfoss
Compatible hose ID IN	0.380
Compatible hose ID MM	9.525
Construction Style	Crimp
End size 1	-10
End type 1	24 deg. DKO swivel light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.866
Hex size 1 MM	22.000
Hose cut off factor IN	1.020
Hose cut off factor MM	25.900
Hose size	-6
Inside diameter IN	0.2600
Inside diameter MM	6.7000
Product height in	0.866
Product height mm	22.000
Product length in	2.015
Product length mm	51.200
Product material	Carbon steel
Product width in	0.866
Product width mm	22.000 mm
Seal material	Nitrile (NBR)
Thread sealant	No
Thread size 1	M18x1.5
Working pressure max BAR	250.00
Working pressure max PSI	3650.00
