Danfoss 459189

DG4V 5 7CJ M U H6 20, DG4V57CJMUH620

MPN: 459189
Category: Manifold directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 459189?

Danfoss DG4V 5 7CJ M U H6 20, DG4V57CJMUH620, manufacturer part number 459189. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation Type	Solenoid operated
Brand	Vickers by Danfoss
Coil Rating	24 VDC
Design Series	20 Series
Electrical Connection	ISO 4400 (Din 43650) connector
Fluid Cleanliness	19/17/14 micron
Fluid compatibility	Petroleum oils
Interface	ISO4401-05
Manual override	Plain
Model Code 1	DG4V57CJMUH620
Pressure rating BAR	315
Pressure rating PSI	4500
Product height in	4.450
Product length in	12.280
Product length mm	311.912
Product width in	2.760
Product width mm	70.104
Seal type	Buna-N
Solenoid Energising ID	Standard as per ANSI B93 9
Spool Type	Spool 7
Spring Arrangement	Spring centred
Stage	Single stage
Valve Mount Type	Subplate/manifold mounted
Valve type	Directional control valve
