Danfoss 4500E
COUPLING,4000,F,3/8,B,-8MNPTF,NBR
- MPN
- 4500E
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 4500E?
Danfoss COUPLING,4000,F,3/8,B,-8MNPTF,NBR, manufacturer part number 4500E. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| EAN/UPC | 678146102386 |
| Angle shape | Straight |
| Body size | 3/8 |
| Compliances | A-A-59439 |
| End size 1 | -8 |
| End type 1 | Male pipe (NPTF) |
| Fluid compatibility | Air, Gas, Liquid |
| Hex size 1 IN | 0.880 |
| Item type | Female half |
| Latch type | Push/pull |
| Product length in | 2.540 |
| Product material | Brass |
| Safety locking mechanism | Pin lock |
| Seal material | Nitrile (NBR) |
| Thread size 1 | 1/2-14 NPTF |
| Valve type | 2 way |
| Working pressure max psi | 1000 |
| Working temperature max F | 250 |
| Working temperature min F | -40 |
4500E: frequently asked questions
When can 4500E be shipped?
4500E is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 4500E in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 4500E and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 4500E, subject to availability and destination.
