Danfoss 4100

COUPLING,4000,F,3/8,B,-4NPT

MPN: 4100
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4100?

Danfoss COUPLING,4000,F,3/8,B,-4NPT, manufacturer part number 4100. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146042071
Angle shape	Straight
Body size	1/8
Burst pressure min bar	276
Burst pressure min psi	4000
Connection style	Manual connect
End size 2	-4
End type 1	Female Push to Connect
End type 2	Male pipe (NPTF)
Flow rate GPM	336.56
Flow rate LPM	1274.02
Fluid compatibility	Air, Gases and liquids
Hex size 1 IN	0.880
Hex size 1 MM	22.352
Item type	Female half
Latch type	Push/pull
Product height in	1.380
Product height mm	35.052
Product length in	2.350
Product length mm	59.690
Product material	Brass
Product width in	1.380
Product width mm	35.052 mm
Safety locking mechanism	Pin lock
Seal material	Nitrile (NBR)
Valve type	2 way
Working pressure max psi	1000
Working pressure max BAR	69
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
