Danfoss 406AA00100A
1CE100P35S8 OVERCENTRE CART PILOT A, 1CE100-P-35-S-8-XXX
- MPN
- 406AA00100A
- Category
- Cartridge valves
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 406AA00100A?
Danfoss 1CE100P35S8 OVERCENTRE CART PILOT A, 1CE100-P-35-S-8-XXX, manufacturer part number 406AA00100A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Adjustment type | Leakproof Screw |
| Brand | Danfoss |
| Cavity | A6610 |
| Flow rate LPM | 100.000 |
| Fluid compatibility | MIL-H-5606, SAE10, SAE20, etc |
| Function | Overcenter Valve |
| Housing | No |
| Installation type | Screw-in Cartridge |
| Leakage | 0.25 cc/min |
| Max load induced p BAR | 270.000 |
| Max pilot adjust p BAR | 28.875 |
| Max relief press BAR | 350.000 |
| Min pilot adjust p BAR | 23.625 |
| Model Code 1 | 1CE100-P-35-S-8-XXX |
| Number of housing ports | 3 |
| Number of valve ports | 3 |
| Operating temperature | -30 C to 90 C (-22 to 194 F) |
| Operation | Pilot operated |
| Pilot ratio | 8:1 |
| Port size | None |
| Port type | Cartridge Only |
| Pressure rating BAR | 350.000 |
| Product height in | 1.490 |
| Product height mm | 37.846 |
| Product length in | 4.780 |
| Product length mm | 121.412 |
| Product width in | 1.490 |
| Product width mm | 37.846 mm |
| Recommended filtration level | 18/16/13 |
| Seal type | Buna-N |
| Special features | None |
| Style | Pilot assisted relief w check |
406AA00100A: frequently asked questions
When can 406AA00100A be shipped?
406AA00100A is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 406AA00100A in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 406AA00100A and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 406AA00100A, subject to availability and destination.
