Danfoss 405AA00145A

2CFP60P6S FLOW REG CARTRIDGE, 2CFP60P6S, 2CFP60-P-6-S

MPN: 405AA00145A
Category: Cartridge valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 405AA00145A?

Danfoss 2CFP60P6S FLOW REG CARTRIDGE, 2CFP60P6S, 2CFP60-P-6-S, manufacturer part number 405AA00145A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Adjustment type	Screw
Brand	Danfoss
Cavity	CVA-27-04-0
Differential pressure BAR	350.00
Differential pressure PSI	5076.32
Factory set flow rate GPM	8.710
Factory set flow rate LPM	33.00
Flow rate GPM	15.850
Flow rate LPM	60.00
Fluid compatibility	MIL-H-5606, SAE10, SAE20, etc
Function	Priority Flow Reg Adjust type
Housing	No
Installation type	Screw-in Cartridge
Leakage	Standard
Maximum flow rate GPM	15.850
Maximum flow rate LPM	60.00
Minimum flow rate GPM	1.580
Minimum flow rate LPM	6.00
Model Code	2CFP60P6S
Model Code 1	2CFP60-P-6-S
Operating temperature	-20 C to 90 C (-4 to 194 F)
Operation	Differential Pressure
Port type	Cartridge Only
Pressure rating BAR	350.00
Pressure rating PSI	5076.00
Product height in	1.000
Product height mm	25.400
Product length in	4.710
Product length mm	119.634
Product width in	1.000
Product width mm	25.400 mm
Proposition 65	Cancer and Reproductive Harm
Rec filtration level	18/16/13
Seal type	Buna-N
Special features	None
Spool seal	No
Style	Adjust Press Compens, Flow Reg
Torque alu cavity	75 Nm
