LE402N-02SM LOGIC ELEMENT, LE402-N-02-SM
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Cartridge valves |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 402AA00459A be shipped?
402AA00459A is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 402AA00459A in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 402AA00459A and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 402AA00459A, subject to availability and destination.
Danfoss LE402N-02SM LOGIC ELEMENT, LE402-N-02-SM, manufacturer part number 402AA00459A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Brand | Danfoss |
| Cavity | C-20-2 |
| Flow rate GPM | 105.669 |
| Flow rate LPM | 400.00 |
| Fluid compatibility | MIL-H-5606, SAE10, SAE20, etc |
| Function | Differential Pressure Sensing |
| Housing | No |
| Installation type | Screw-in Cartridge |
| Leakage | Standard |
| Model Code 1 | LE402-N-02-SM |
| Number housing ports | 3 |
| Number of valve port | 3 |
| Operating temp | -30 C to 90 C (-22 to 194 F) |
| Operation | Pilot operated |
| Port type | Cartridge Only |
| Pressure differential BAR | 0.25 |
| Pressure differential PSI | 3.63 |
| Pressure rating BAR | 250.00 |
| Pressure rating PSI | 3625.94 |
| Product height in | 1.810 |
| Product height mm | 45.974 |
| Product length in | 3.890 |
| Product length mm | 98.806 |
| Product width in | 1.810 |
| Product width mm | 45.974 mm |
| Rec filtration level | 18/16/13 |
| Seal type | Viton |
| Spring | 0.25 bar |
| Stroke adjustment | None |
| Style | Spool |
