Danfoss 320-BG

Valve Brass Shutoff 90D

MPN: 320-BG
Category: Adapters and swivel joints

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 320-BG?

Danfoss Valve Brass Shutoff 90D, manufacturer part number 320-BG. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Angle shape	90 Degree
Brand	Weatherhead by Danfoss
End Type 1	Male pipe (NPTF)
End Type 2	Male 37 degree
Hex size 1 IN	0.438
Hex size 1 MM	11.100
Item type	Adapter-elbow
Product material	Brass
Thread sealant	No
Thread size 2	7/16-20 UNF
Tube outside diameter 1 IN	0.260
Tube outside diameter 1 MM	6.6
Tube outside diameter 2 IN	0.180
Tube outside diameter 2 MM	4.6
Working pressure bar	10.0
Working pressure psi	150
Working temp max C	121
Working temp max F	250
Working temp min C	-54
Working temp min F	-65
