Danfoss 310
COUPLING,3000,F,1/4,B,-6NPT,NBR
- MPN
- 310
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 310?
Danfoss COUPLING,3000,F,1/4,B,-6NPT,NBR, manufacturer part number 310. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| EAN/UPC | 678146100887 |
| Angle shape | Straight |
| Body size | 3/8 |
| Burst pressure min bar | 69 |
| Burst pressure min psi | 1000 |
| Connection style | Manual connect |
| End size 2 | -6 |
| End type 1 | Female Push to Connect |
| End type 2 | Female pipe (NPTF) |
| Finish plating | Zinc |
| Flow rate GPM | 374.00 |
| Flow rate LPM | 1415.74 |
| Fluid compatibility | Compressed air, Gases and liquids |
| Hex size 1 IN | 0.940 |
| Hex size 1 MM | 23.876 |
| Item type | Female half |
| Latch type | Push/pull |
| Product height in | 1.210 |
| Product height mm | 30.734 |
| Product length in | 2.100 |
| Product length mm | 53.340 |
| Product material | Carbon steel |
| Product width in | 1.210 |
| Product width mm | 30.734 mm |
| Safety locking mechanism | Pin lock |
| Seal material | Nitrile (NBR) |
| Valve type | 2 way |
| Working pressure max psi | 250 |
| Working pressure max BAR | 17 |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
