Danfoss 2R21143

Cplng, 2RL SERIES FEMALE, STEEL

MPN: 2R21143
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 2R21143?

Danfoss Cplng, 2RL SERIES FEMALE, STEEL, manufacturer part number 2R21143. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146165046
Angle shape	Straight
Body size	1/4
Brand	Danfoss
Burst pressure min bar	83
Burst pressure min psi	1200
Connection style	Manual connect
End size 2	-6
End type 1	Female Push to Connect
End type 2	Female pipe (NPTF)
Finish plating	Zinc
Flow rate GPM	356.00
Flow rate LPM	1347.61
Fluid compatibility	Compressed air
Hex size 1 IN	0.880
Hex size 1 MM	22.352
Item type	Female half
Latch type	Push/pull
Product length in	2.160
Product material	Carbon steel
Safety locking mechanism	Ring lock
Seal material	Fluorocarbon (FKM)
Sub brand	Hansen
Working pressure max psi	300
Working pressure max BAR	21
Working temperature max C	200
Working temperature max F	392
Working temperature min C	-20
Working temperature min F	-4

2R21143: frequently asked questions

When can 2R21143 be shipped?

2R21143 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 2R21143 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 2R21143 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 2R21143, subject to availability and destination.
