Danfoss 2H6143

Cplng, HK SERIES FEMALE, STEEL

MPN: 2H6143
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 2H6143?

Danfoss Cplng, HK SERIES FEMALE, STEEL, manufacturer part number 2H6143. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146035400
Air inclusion max cc	1.20
Air inclusion max in3	0.07
Angle shape	Straight
Body size	1/4
Brand	Danfoss
Connection style	Manual connect
End size 2	9/16"
End type 1	Female Push to Connect
End type 2	Female 37 degree swivel
Finish plating	Zinc
Flow rate GPM	3.00
Flow rate LPM	11.36
Fluid compatibility	Hydraulic fluid
Fluid loss cc	0.90000
Fluid loss in3	0.05500
Hex size 1 IN	0.880
Hex size 1 MM	22.352
Item type	Female half
Latch type	Push/pull
Product length in	2.400
Product material	Carbon steel
Safety locking mechanism	None
Seal material	Fluorocarbon (FKM)
Sub brand	Hansen
Valve type	2 way
Working pressure max psi	5000
Working pressure max BAR	345
Working temperature max C	204
Working temperature max F	400
Working temperature min C	-26
Working temperature min F	-15

2H6143: frequently asked questions

When can 2H6143 be shipped?

2H6143 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 2H6143 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 2H6143 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 2H6143, subject to availability and destination.
