Danfoss 282-1005-003

REPLACED BY 282-1005-004, ABY86B800DA000000GAAA3A0AA00C

MPN: 282-1005-003
Category: Hydraulic steering units

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 282-1005-003?

Danfoss REPLACED BY 282-1005-004, ABY86B800DA000000GAAA3A0AA00C, manufacturer part number 282-1005-003. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Additional ports	None
Brand	Danfoss
Cylinder relief setting	None
Design code	3
Displacement	3030 cm3/r [185.0 in3/r]
Flow amplification	None
Fluid type	Per Danfoss bulletin 3-401
Identification	Danfoss number on tag
Inlet pressure rating	241 bar [3500 lbf / in2]-ductile housing
Inlet relief setting	None
Input torque	Standard
Load circuit	Non reaction
Model Code 1	ABY86B800DA000000GAAA3A0AA00C
Mounting threads	4x 3/8-16 on mount face
Neutral circuit	Closed center with neutral bleed
Nominal flow rating	151 L/min [40.00 gal/min]
P,T,L, and R port size	1.3125-12 sae o-ring port
Paint and packaging	No paint
Product Series	ABY Series 40
Return pressure rating	21 bar [305 lbf/in2] maximum
Special application option	None
Special features	None
Valve options	None
