Danfoss 25FFS100143

COUPLING,FF,F,1",CS,-16NPT,FKM

MPN: 25FFS100143
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 25FFS100143?

Danfoss COUPLING,FF,F,1",CS,-16NPT,FKM, manufacturer part number 25FFS100143. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146197757
Air inclusion max cc	0.03
Angle shape	Straight
Application	Agriculture, Building material, Commercial vehicles, Fluid transfer, Hydraulics, Road vehicles
Body size	1"
Brand	Danfoss
Burst pressure min psi	18270
Certifications	ISO 16028
Compliances	PED 2014/68 EU Article 4.3, REACH, RoHS Compliant
Connection style	Manual connect
End size 1	-16
End type 1	Female Pipe (NPT)
Finish plating	Guardian sealtm
Flow rate GPM	48.60
Fluid compatibility	Hydraulic fluid
Fluid loss cc	0.03200
Hex size 1 IN	2.170
Item type	Female half
Latch type	Push to connect
Product material	Carbon steel
Safety locking mechanism	Sleeve lock
Seal material	Fluorocarbon (FKM)
Sub brand	Hansen
Thread size 1	1-11 1/2 NPT
Torque lbs-ft	58.50
Valve type	2 way
Working pressure max psi	5800
Working temperature max F	392
Working temperature min F	-4
