Danfoss 25503-LSA
GR PUMP (L2-DIST)
- MPN
- 25503-LSA
- Category
- Rugid aluminum gear pumps
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 25503-LSA?
Danfoss GR PUMP (L2-DIST), manufacturer part number 25503-LSA. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Brand | Danfoss |
| Design code | A |
| Displacement | 33.6 cm3/r [2.05 in3/r] |
| Identification | Standard |
| Input shaft | 13 tooth 16/32 spline, min full spline 22.2 [.88], shaft ext 41.1[1.62] |
| Paint | Primer per spec 209-13a |
| Ports and location | Plain: suction port 1.625-12 UN-2b SAE o-ring port; pressure port 1.0625-12 UN-2b SAE o-ring port - side ports |
| Priority flow divider setting | No flow setting |
| Product | L2 gear pump (single unit) |
| Rear mounting | No auxiliary mounting features |
| Relief valve full flow setting | No relief valve setting |
| Rotation | Left-hand rotation (ccw) |
| Special features | Generic |
| Unit type | Plain |
25503-LSA: frequently asked questions
When can 25503-LSA be shipped?
25503-LSA is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 25503-LSA in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 25503-LSA and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 25503-LSA, subject to availability and destination.
