Danfoss 210215
COUPLING,210/310,F,1/4,CS,-6BARB
- MPN
- 210215
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 210215?
Danfoss COUPLING,210/310,F,1/4,CS,-6BARB, manufacturer part number 210215. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| EAN/UPC | 678146165435 |
| Angle shape | Straight |
| Body size | 1/4 |
| Burst pressure min bar | 69 |
| Burst pressure min psi | 1000 |
| Connection style | Manual connect |
| End type 1 | Female Push to Connect |
| End type 2 | Line/hose/tube |
| Finish plating | Zinc |
| Flow rate GPM | 142.00 |
| Flow rate LPM | 537.53 |
| Fluid compatibility | Compressed air, Gases and liquids |
| Item type | Female half |
| Latch type | Push/pull |
| Product length in | 2.390 |
| Product material | Carbon steel |
| Safety locking mechanism | Pin lock |
| Seal material | Nitrile (NBR) |
| Valve type | 2 way |
| Working pressure max psi | 250 |
| Working pressure max BAR | 17 |
| Working temperature max C | 93 |
| Working temperature max F | 200 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
