Danfoss 20511Y-36-12EQSVT

HOSE NIPPLE ASSY,2P/12,DKOH-B/36,AP,STR

MPN
20511Y-36-12EQSVT
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 20511Y-36-12EQSVT?

Danfoss HOSE NIPPLE ASSY,2P/12,DKOH-B/36,AP,STR, manufacturer part number 20511Y-36-12EQSVT. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

A dimension IN2.890
A dimension MM73.500
Angle shapeStraight
BrandWinner by Danfoss
Compatible hose ID IN0.750
Compatible hose ID MM19.000
Construction StyleCrimp
End connection torque125-140 lb-ft(170-190 Nm)
End Type 124 deg. DKO swivel heavy duty
Hex size 1 IN1.813
Hex size 1 MM46.000
Hex size 2 IN1.810
Hex size 2 MM45.974
Hose cut off factor IN1.370
Hose cut off factor MM35.000
Hose size-12
Inside diameter IN0.590
Inside diameter MM15.000
Product height in1.555
Product height mm39.497
Product length in2.980
Product length mm75.692
Product material316L Stainless steel
Product width in1.555
Product width mm39.497
SeriesWinner 2-Piece
Thread sealantNo
Thread size 1M36x2
Tube OD 1 IN0.980
Tube OD 1 MM25.000

20511Y-36-12EQSVT: frequently asked questions

When can 20511Y-36-12EQSVT be shipped?

20511Y-36-12EQSVT is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 20511Y-36-12EQSVT in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 20511Y-36-12EQSVT and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 20511Y-36-12EQSVT, subject to availability and destination.
