Danfoss 20491-16-06WZF

HOSE NIPPLE ASSY,2P/06,DKOL/16,CS,90D

MPN: 20491-16-06WZF
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 20491-16-06WZF?

Danfoss HOSE NIPPLE ASSY,2P/06,DKOL/16,CS,90D, manufacturer part number 20491-16-06WZF. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.559
A dimension MM	65.000
Angle shape	90 Degree
Brand	Winner by Danfoss
Compatible hose ID IN	0.380
Compatible hose ID MM	9.500
Construction Style	Crimp
Drop dimension IN	1.300
Drop dimension MM	33.00
End connection torque	33-40 lb-ft(45-55 Nm)
End size 1	-8
End Type 1	24 deg. DKO swivel light duty
Finish plating	Zinc plating
Hose cut off factor IN	1.377
Hose cut off factor MM	35.000
Hose size	-6
Inside diameter IN	0.220
Inside diameter MM	5.500
Product height in	2.031
Product height mm	51.587
Product length in	3.129
Product length mm	79.476
Product material	Carbon steel
Product width in	0.750
Product width mm	19.05
Seal material	Nitrile (NBR)
Series	Winner 2-Piece
Thread size 1	M16x1.5
Tube OD 1 IN	0.393
Tube OD 1 MM	10.000
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40
