Danfoss 20441-14-05WZ

HOSE NIPPLE, 2P/05, DKOL/14, CS, STR

MPN
20441-14-05WZ
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 20441-14-05WZ?

Danfoss HOSE NIPPLE, 2P/05, DKOL/14, CS, STR, manufacturer part number 20441-14-05WZ. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

A dimension IN2.602
A dimension MM66.100
Angle shapeStraight
BrandWinner by Danfoss
Compatible hose ID IN0.310
Compatible hose ID MM7.900
Construction StyleCrimp
Drop dimension IN0.629
Drop dimension MM16.00
End connection torque18-20 lb-ft(24-27 Nm)
End size 1-14
End Type 124 deg. DKO swivel light duty
Finish platingZinc plating
Hex size 1 IN0.669
Hex size 1 MM16.993
Hex size 2 IN0.670
Hex size 2 MM17.018
Hose cut off factor IN1.500
Hose cut off factor MM38.100
Hose size-5
Inside diameter IN0.216
Inside diameter MM5.500
Product height in2.830
Product height mm71.882
Product length in4.460
Product length mm113.284
Product materialCarbon steel
Product width in0.670
Product width mm17.018
SeriesWinner 2-Piece
Thread sealantNo
Thread size 1M14x1.5
Working temperature max C100
Working temperature max F212
Working temperature min C-40
Working temperature min F-40

20441-14-05WZ: frequently asked questions

When can 20441-14-05WZ be shipped?

20441-14-05WZ is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 20441-14-05WZ in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 20441-14-05WZ and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 20441-14-05WZ, subject to availability and destination.
