Adapter-STR,1DB-WD,16S-12,CS,NBR,Z

Name: Danfoss 1DB-24-12WDRNWZ – Adapter-STR,1DB-WD,16S-12,CS,NBR,Z
Brand: Danfoss (Drives)
SKU: 1DB-24-12WDRNWZ

MPN: 1DB-24-12WDRNWZ · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Tube fittings
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 1DB-24-12WDRNWZ be shipped?

1DB-24-12WDRNWZ is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1DB-24-12WDRNWZ in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1DB-24-12WDRNWZ and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1DB-24-12WDRNWZ, subject to availability and destination.

Danfoss Adapter-STR,1DB-WD,16S-12,CS,NBR,Z, manufacturer part number 1DB-24-12WDRNWZ. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Brand	Winner by Danfoss
Complete connector	Yes
End size 1	16S
End size 2	-12
End Type 1	24 degree tube port heavy duty
End Type 2	Male 1179-2 BSPP type E (heavy duty)
Finish plating	Zinc
Hex size 1 MM	30.000
Hex size 3 MM	32.0
Item type	Adapter-straight
Product material	Carbon steel
Product serial name	1DB-WD
Seal material	Nitrile (NBR)
Thread size 1	M24x1.5
Thread size 2	G 3/4
