Danfoss 1CG-12-02SRRN – Adapter-STR,1CG,6L-2,304,FKM,PA

Name: Danfoss 1CG-12-02SRRN – Adapter-STR,1CG,6L-2,304,FKM,PA
Brand: Danfoss (Drives)
SKU: 1CG-12-02SRRN

MPN: 1CG-12-02SRRN · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Tube fittings
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 1CG-12-02SRRN be shipped?

1CG-12-02SRRN is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1CG-12-02SRRN in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1CG-12-02SRRN and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1CG-12-02SRRN, subject to availability and destination.

Danfoss Adapter-STR,1CG,6L-2,304,FKM,PA, manufacturer part number 1CG-12-02SRRN. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Brand	Winner by Danfoss
Complete connector	Yes
End size 1	6L
End size 2	-2
End type 1	24 deg. tube port light duty
End type 2	Male ORB BSPP
Finish plating	Passivate
Hex size 1 MM	14.0
Hex size 5 MM	14.0
Item type	Adapter-straight
Product material	304 Stainless steel
Product serial name	1CG
Seal material	Fluorocarbon (FKM)
Thread sealant	No
Thread size 1	M12x1.5
Thread size 2	G 1/8
