Danfoss 1AA12MR10

HOSE FTG, 1A/10, ORS-M/12, CS, STR

MPN: 1AA12MR10
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1AA12MR10?

Danfoss HOSE FTG, 1A/10, ORS-M/12, CS, STR, manufacturer part number 1AA12MR10. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146125828
A dimension IN	2.260
A dimension MM	57.300
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.620
Compatible hose ID MM	15.900
Construction Style	Crimp
End connection torque	65-70 lb-ft(88-95 Nm)
End size 1	-12
End Type 1	Male ORFS
Finish plating	Dura-Kote
Hex size 2 MM	32.000
Hose cut off factor IN	1.240
Hose cut off factor MM	31.400
Hose size	-10
Inside diameter IN	0.500
Inside diameter MM	12.800
Product height in	1.440
Product height mm	36.576
Product length in	2.390
Product length mm	60.706
Product material	Carbon steel
Product width in	1.390
Product width mm	35.306
Series	1A/Z Series
Thread size 1	1 3/16-12 UN
Working pressure max BAR	414.00
Working pressure max PSI	6000.00
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
