Danfoss 1A10BFB10

HOSE FTG, 1A/10, BF/10, CS, 90D

MPN: 1A10BFB10
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1A10BFB10?

Danfoss HOSE FTG, 1A/10, BF/10, CS, 90D, manufacturer part number 1A10BFB10. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146123206
A dimension IN	3.570
A dimension MM	90.600
Angle shape	90 Degree
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.620
Compatible hose ID MM	15.900
Construction Style	Crimp
Drop dimension IN	2.220
Drop dimension MM	56.30
End size 1	-10
End Type 1	Female BSPP swivel
Finish plating	Dura-Kote
Hex size 1 IN	1.060
Hex size 1 MM	26.924
Hose cut off factor IN	2.410
Hose cut off factor MM	61.200
Hose size	-10
Inside diameter IN	0.500
Inside diameter MM	12.800
Product height in	3.400
Product height mm	86.360
Product length in	4.100
Product length mm	104.414
Product material	Carbon steel
Product width in	1.390
Product width mm	35.306
Proposition 65	Cancer and Reproductive Harm
Series	1A/Z Series
Thread sealant	No
Thread size 1	G 5/8
Working pressure max BAR	350.00
Working pressure max PSI	5100.00
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
