Danfoss 17811-06-06Z

HOSE NIPPLE ASSY,2P/06,45D-M/06,CS,STR

MPN
17811-06-06Z
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 17811-06-06Z?

Danfoss HOSE NIPPLE ASSY,2P/06,45D-M/06,CS,STR, manufacturer part number 17811-06-06Z. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

A dimension IN2.300
A dimension MM58.500
Angle shapeStraight
BrandWinner by Danfoss
Compatible hose ID IN0.380
Compatible hose ID MM9.500
Construction StyleCrimp
End size 1-6
End size 2-6
End Type 1Male 45 degree inverted flare
End Type 2Line/hose/tube
Finish platingZinc plating
Hex size 1 IN0.670
Hex size 1 MM17.018
Hose cut off factor IN1.120
Hose cut off factor MM28.500
Hose size-6
Inside diameter IN0.280
Inside diameter MM7.000
Product height in0.770
Product height mm19.558
Product length in2.303
Product length mm58.496
Product materialCarbon steel
Product width in0.670
Product width mm17.018
SeriesWinner 2-Piece
Thread sealantNo
Thread size 15/8-18 UNF

17811-06-06Z: frequently asked questions

When can 17811-06-06Z be shipped?

17811-06-06Z is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 17811-06-06Z in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 17811-06-06Z and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 17811-06-06Z, subject to availability and destination.
